Product Description
Maximum cutting speed is 750mm/s Table top type cutting plotter with excelent cost performance
Flatbed cutting plotter is used for not only sign making but also for a wide range of industrial applicaitons and processes. Max.750mm/s cutting speed is useful for getting high productivity. The FC4500 Series are professional flatbed cutting plotters capable of processing a wide variety of materials with accuracy. Compact size that can be set on a table with precise control of contour cut, half cut,perforated cut, and plotting.this FC4500 series is the most economical solution for cutting thick, hard materials that cannot be fed through a grit rolling type cutting plotter.
Model name FC4550-50 FC4510-60 Configuration Digital servo system, Flatbed Media hold-down method Cling mat Adhesive sheet / mat Effective cutting area 590 x 430 mm (23.2 x 16.9 inch) 860 x 600 mm (33.8 x 23.6 inch) Mountable media 500 mm (19.6 inch)
(Y-axis direction) 666 mm (26.2 inch)
(Y-axis direction) Media type Marking film (vinyl, fluorescent, and reflective)
Stiff paper/card (for stencils, etc.) up to 0.5 mm thick *1
Polystyrene foam sheets up to 0.8 mm thick *2
Sandblast rubber sheets up to 1.0 mm thick *2
Microflute board (F/G grades)
Clear sheets for plastic boxes
High-intensity reflective film *3 Maximum cutting speed 750 mm/s (30 inch/s) (1 to 75 cm/s in 23 steps) Cutting pressure Tool 1: Max. 5.88 N
(600 gf), in 48 steps
Tool 2: Max. 2.94 N
(300 gf), in 30 steps Tool 1, Tool 2: Max. 5.88 N
(600 gf), in 48 steps Minimum character size approx. 5 mm square (varies with the character font and media) Mechanical resolution 0.005 mm (5μm) Programmable resolution GP-GL mode: 0.1/0.05/0.025/0.01 mm, HP-GL™ *4 : 0.025 mm Distance accuracy Max 0.2% of the distance moved or 0.1 mm, whichever is larger *5 Perpendicularity Max 0.3 mm / 430 mm Max 0.4 mm / 610 mm Repeatability Max 0.1 mm *5 Standard interfaces RS-232C, USB2.0 (High speed) Buffer memory 2 Mbyte Command sets GP-GL and HP-GL™ *4 emulation (selected by menu) Number of tools 2 tools Cutter blade, pen,
and tool types Cutter blade: supersteel
Pen: oil-based ballpoint pen
Creasing/scoring tool Others ARMS (Advanced Registration Mark Sensing System), Reverse-side cutting and creasing with ARMS, Copy function, Creasing function, Repeatedly cut function Power supply 100 to 240 VAC, 50/60 Hz (Auto switching) Power consumption Max. 120 VA Operating environment Temperature: +10 to +35 degree C (44 to 95 degree F) , Humidity: 35 to 75% RH (non-condensing) Guaranteed accuracy environment Temperature: +16 to +32 degree C (55 to 90 degree F), Humidity: 35% to 70% RH (non-condensing) External dimensions
(W x D x H) *6 857 x 780 x 200 mm *7
(33.7 x 30.7 x 7.9 inch) 1172 x 962 x 200 mm *7
(46.1 x 37.9 x 7.9 inch) Weight approx. 19 kg (42 lbs.) approx. 27 kg *10 (60 lbs.) Compatible OS *8 Windows 10 / 8.1 / 8 / 7 / Vista, Mac OS 10.6 to 10.10 Certifications UL , cUL , CE making, FCC-A, EN55022-A, RoHS
Flatbed cutting plotter is used for not only sign making but also for a wide range of industrial applicaitons and processes. Max.750mm/s cutting speed is useful for getting high productivity. The FC4500 Series are professional flatbed cutting plotters capable of processing a wide variety of materials with accuracy. Compact size that can be set on a table with precise control of contour cut, half cut,perforated cut, and plotting.this FC4500 series is the most economical solution for cutting thick, hard materials that cannot be fed through a grit rolling type cutting plotter.
Model name | FC4550-50 | FC4510-60 |
---|---|---|
Configuration | Digital servo system, Flatbed | |
Media hold-down method | Cling mat | Adhesive sheet / mat |
Effective cutting area | 590 x 430 mm (23.2 x 16.9 inch) | 860 x 600 mm (33.8 x 23.6 inch) |
Mountable media | 500 mm (19.6 inch) (Y-axis direction) | 666 mm (26.2 inch) (Y-axis direction) |
Media type | Marking film (vinyl, fluorescent, and reflective) Stiff paper/card (for stencils, etc.) up to 0.5 mm thick *1 Polystyrene foam sheets up to 0.8 mm thick *2 Sandblast rubber sheets up to 1.0 mm thick *2 Microflute board (F/G grades) Clear sheets for plastic boxes High-intensity reflective film *3 | |
Maximum cutting speed | 750 mm/s (30 inch/s) (1 to 75 cm/s in 23 steps) | |
Cutting pressure | Tool 1: Max. 5.88 N (600 gf), in 48 steps Tool 2: Max. 2.94 N (300 gf), in 30 steps | Tool 1, Tool 2: Max. 5.88 N (600 gf), in 48 steps |
Minimum character size | approx. 5 mm square (varies with the character font and media) | |
Mechanical resolution | 0.005 mm (5μm) | |
Programmable resolution | GP-GL mode: 0.1/0.05/0.025/0.01 mm, HP-GL™ *4 : 0.025 mm | |
Distance accuracy | Max 0.2% of the distance moved or 0.1 mm, whichever is larger *5 | |
Perpendicularity | Max 0.3 mm / 430 mm | Max 0.4 mm / 610 mm |
Repeatability | Max 0.1 mm *5 | |
Standard interfaces | RS-232C, USB2.0 (High speed) | |
Buffer memory | 2 Mbyte | |
Command sets | GP-GL and HP-GL™ *4 emulation (selected by menu) | |
Number of tools | 2 tools | |
Cutter blade, pen, and tool types | Cutter blade: supersteel Pen: oil-based ballpoint pen Creasing/scoring tool | |
Others | ARMS (Advanced Registration Mark Sensing System), Reverse-side cutting and creasing with ARMS, Copy function, Creasing function, Repeatedly cut function | |
Power supply | 100 to 240 VAC, 50/60 Hz (Auto switching) | |
Power consumption | Max. 120 VA | |
Operating environment | Temperature: +10 to +35 degree C (44 to 95 degree F) , Humidity: 35 to 75% RH (non-condensing) | |
Guaranteed accuracy environment | Temperature: +16 to +32 degree C (55 to 90 degree F), Humidity: 35% to 70% RH (non-condensing) | |
External dimensions (W x D x H) *6 | 857 x 780 x 200 mm *7 (33.7 x 30.7 x 7.9 inch) | 1172 x 962 x 200 mm *7 (46.1 x 37.9 x 7.9 inch) |
Weight | approx. 19 kg (42 lbs.) | approx. 27 kg *10 (60 lbs.) |
Compatible OS *8 | Windows 10 / 8.1 / 8 / 7 / Vista, Mac OS 10.6 to 10.10 | |
Certifications | UL , cUL , CE making, FCC-A, EN55022-A, RoHS |
