Product Description
Mimaki’s high-specification entry model
- Silver ink creates high-value-added printing
・Newly developed SS21 silver ink delivers brilliant print results.
・The metallic color collection contains 648 colors.
- Orange and light black inks ensure faithful color representation
・SS21 orange ink is suitable for representing the vibrancy of fresh foods as well as corporate color palettes.
・SS21 light black ink reproduces highly accurate grayscale printing with no unexpected color shifts and smooth grayscale gradation without tone-jump.
- Mimaki’s superior print-image quality control technology
・Highly reliable inkjet technology optimizes waveform to achieve the precise placement of the ink droplets onto media.
・Three-way intelligent heater system optimizes the ink droplets size.
・MAPS3 reduces banding and uneven color printing.
- Versatile print and cut functions
・The continuous register mark detection function enables the continuous cutting of a whole roll of media while simultaneously taking up unrolled media.
・The over-cut and corner-cut functions ensure clearly cut edges with no residues.
・The segment correction function facilitates precision cutting over longer-length prints.
・The cut-and-print function averts printing problems by cutting the media prior to printing.
- Silver ink creates high-value-added printing
・Newly developed SS21 silver ink delivers brilliant print results.
・The metallic color collection contains 648 colors. - Orange and light black inks ensure faithful color representation
・SS21 orange ink is suitable for representing the vibrancy of fresh foods as well as corporate color palettes.
・SS21 light black ink reproduces highly accurate grayscale printing with no unexpected color shifts and smooth grayscale gradation without tone-jump. - Mimaki’s superior print-image quality control technology
・Highly reliable inkjet technology optimizes waveform to achieve the precise placement of the ink droplets onto media.
・Three-way intelligent heater system optimizes the ink droplets size.
・MAPS3 reduces banding and uneven color printing. - Versatile print and cut functions
・The continuous register mark detection function enables the continuous cutting of a whole roll of media while simultaneously taking up unrolled media.
・The over-cut and corner-cut functions ensure clearly cut edges with no residues.
・The segment correction function facilitates precision cutting over longer-length prints.
・The cut-and-print function averts printing problems by cutting the media prior to printing.
CJV150-75
Suitable for simple stickers and labels
・Max. Print / Cut Width：800 (31.5")mm
・Max. Media Width：810 (31.9")mm
Suitable for simple stickers and labels
・Max. Print / Cut Width：800 (31.5")mm
・Max. Media Width：810 (31.9")mm
CJV150-107
Suitable for quick POPs and large-size posters
・Max. Print / Cut Width：1,090 (42.9")mm
・Max. Media Width：1,100 (43.3")mm
Suitable for quick POPs and large-size posters
・Max. Print / Cut Width：1,090 (42.9")mm
・Max. Media Width：1,100 (43.3")mm
CJV150-130
Suitable for variously sized signage and
point-of-sale marketing materials
・Max. Print / Cut Width：1,361 (53.6")mm
・Max. Media Width：1,371 (54.0")mm
Suitable for variously sized signage and
point-of-sale marketing materials
・Max. Print / Cut Width：1,361 (53.6")mm
・Max. Media Width：1,371 (54.0")mm
CJV150-160
Suitable for cost effective production of
large, high-quality signage and
vehicle wrapping films
・Max. Print / Cut Width：1,610 (63.4")mm
・Max. Media Width：1,620 (63.8")mm
CJV150-75 CJV150-107 CJV150-130 CJV150-160 Printhead On-demand piezo head Print resolution 360 dpi, 540 dpi, 720 dpi, 1,080 dpi, and 1,440 dpi Maximum print width 800mm (31.5") 1,090mm (42.9") 1,361mm (53.6") 1,610mm (63.4") Maximum media width 810mm (31.9") 1,100mm (43.3") 1,371mm (54.0") 1,620mm (63.8") Ink Type/Color Eco-solvent ink
・SS21（C,M,Y,K,Lc,Lm,Lk,Or,W and Si）
・BS3（C,M,Y, and K） only available in emerging countries
・BS4（C,M,Y, and K） only available in emerging countries
・ES3（C,M,Y,K,Lc,Lm, and W）
Sublimation ink *1
・Sb53（Bl,M,Y,K/Dk,Lbl, and Lm）
・Sb54（Bl,M,Y,K,Lbl, and Lm） Package size
*2 SS21: 440ml Ink cartridge / 2L Ink pack
(* W and Si are provided in 220ml ink cartridges only)
BS3, BS4: 600ml Ink pack / 2L Ink pack
ES3: 440ml Ink cartridge
(* W is provided in 220ml ink cartridge only)
Sb53, Sb54: 440ml Ink cartridge / 2L Ink pack Circulation
system MCT （Mimaki Circulation Technology） Only applies to white and silver inks Media thickness 1.0 mm or less Rolled media weight 40 kg (88 lb) or less Certifications VCCI class A, FCC class A, ETL UL 60950-1
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, Energy Star, RCM
(CCC is in the process of being acquired.) Interface USB 2.0, LAN for E-mail notification function Power supply Single-phase (AC 100–120V / AC 220–240V) Power consumption 100V:1.44 kVA × 1 or less / 200V: 1.92 kVA × 1 or less Operational environment Temperature: 20–30 °C (68–86 °F)
Humidity: 35–65% Rh (Non condensing) Dimensions (W×D×H) 1,965mm × 700mm × 1,392mm (77"×28"×55") 2,255mm × 700mm × 1,392mm (89"×28"×55") 2,525mm × 700mm × 1,392mm (99"×28"×55") 2,775mm × 700mm × 1,392mm (109"×28"×55") Weight 126kg (278 lb) 142kg (313 lb) 157kg (346 lb) 168kg (370 lb)
*1 Sublimation ink "Sb53" is not compatible with the CJV150-75 model.
*2 Optional Mimaki bulk ink system 3 (MBIS3) is required for using 2L Ink pack.
Suitable for cost effective production of
large, high-quality signage and
vehicle wrapping films
・Max. Print / Cut Width：1,610 (63.4")mm
・Max. Media Width：1,620 (63.8")mm
| CJV150-75 | CJV150-107 | CJV150-130 | CJV150-160 | ||
|---|---|---|---|---|---|
| Printhead | On-demand piezo head | ||||
| Print resolution | 360 dpi, 540 dpi, 720 dpi, 1,080 dpi, and 1,440 dpi | ||||
| Maximum print width | 800mm (31.5") | 1,090mm (42.9") | 1,361mm (53.6") | 1,610mm (63.4") | |
| Maximum media width | 810mm (31.9") | 1,100mm (43.3") | 1,371mm (54.0") | 1,620mm (63.8") | |
| Ink | Type/Color | Eco-solvent ink ・SS21（C,M,Y,K,Lc,Lm,Lk,Or,W and Si） ・BS3（C,M,Y, and K） only available in emerging countries ・BS4（C,M,Y, and K） only available in emerging countries ・ES3（C,M,Y,K,Lc,Lm, and W） Sublimation ink *1 ・Sb53（Bl,M,Y,K/Dk,Lbl, and Lm） ・Sb54（Bl,M,Y,K,Lbl, and Lm） | |||
| Package size *2 | SS21: 440ml Ink cartridge / 2L Ink pack (* W and Si are provided in 220ml ink cartridges only) BS3, BS4: 600ml Ink pack / 2L Ink pack ES3: 440ml Ink cartridge (* W is provided in 220ml ink cartridge only) Sb53, Sb54: 440ml Ink cartridge / 2L Ink pack | ||||
| Circulation system | MCT （Mimaki Circulation Technology） Only applies to white and silver inks | ||||
| Media thickness | 1.0 mm or less | ||||
| Rolled media weight | 40 kg (88 lb) or less | ||||
| Certifications | VCCI class A, FCC class A, ETL UL 60950-1 CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM (CCC is in the process of being acquired.) | ||||
| Interface | USB 2.0, LAN for E-mail notification function | ||||
| Power supply | Single-phase (AC 100–120V / AC 220–240V) | ||||
| Power consumption | 100V:1.44 kVA × 1 or less / 200V: 1.92 kVA × 1 or less | ||||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) | ||||
| Dimensions (W×D×H) | 1,965mm × 700mm × 1,392mm (77"×28"×55") | 2,255mm × 700mm × 1,392mm (89"×28"×55") | 2,525mm × 700mm × 1,392mm (99"×28"×55") | 2,775mm × 700mm × 1,392mm (109"×28"×55") | |
| Weight | 126kg (278 lb) | 142kg (313 lb) | 157kg (346 lb) | 168kg (370 lb) | |
*1 Sublimation ink "Sb53" is not compatible with the CJV150-75 model.
*2 Optional Mimaki bulk ink system 3 (MBIS3) is required for using 2L Ink pack.
Ink set
SS21
［C,M,Y,K,Lc,Lm,Lk,Or,W,Si］ C M Y K C M Y K Lc Lm Lk Or C M Y K Lc Lm W C M Y K Lc Lm W Si C M Y K Lk Or W C M Y K Lk Or W Si BS3
［C,M,Y,K］ C M Y K BS4
［C,M,Y,K］ C M Y K ES3
［C,M,Y,K,Lc,Lm,W］ C M Y K C M Y K Lc Lm C M Y K Lc Lm W Sb53
［Bl,M,Y,K/Dk,Lbl,Lm］ Bl M Y K/Dk Bl M Y K/Dk Lbl Lm Sb54
［Bl,M,Y,K,Lbl,Lm］ Bl M Y K Bl M Y K Lbl Lm
- Some of the screens and printing samples in this website are artificial renderings.
- Specifications are subject to change without notice.
- All trademarks or registered trademarks are the property of their respective owners.
- Inkjet printers print using extremely fine dots, thus colors may vary slightly following replacement of the printing heads. Also note that if using multiple printer units, colors may vary slightly among the units due to slight individual differences among the units.
